CRANE® Historic 3 Column Cast Iron Radiators – 1050mm
- Description
-
The 1050mm CRANE® Historic 3 Column Cast Iron Radiator is a tall, statement piece with generous heat output — ideal for larger rooms, high ceilings and traditional hallways where you want heritage looks and serious performance.
The deeper 3-column body gives you more surface area than a 2-column radiator, while keeping the same refined Historic styling with smooth edges, balanced feet and period-correct proportions.
All CRANE® radiators are assembled and pressure tested in the United Kingdom and supplied with a Lifetime Guarantee.
- Customisation and Finishes
-
CRANE Cast Iron Radiators are cast in Europe and assembled and finished at our UK facility.
CRANE Radiators are available painted in any RAL colour, and we also offer a wide range of specialist finishes including polished options from satin to near mirror.
- Technical Data
-
Section Height 1050mm BTU's per section 420 Watts per section 123 Radiator Depth 110mm Section Length 60mm Carbon (C) 3.40%-3.85% Silicon (Si) 1.80%-2.10% Sulfur (S) <0.06% Phosphorus (P) <0.10% Manganese (Mn) 0.40%-0.85% Chromium (Cr) <0.07% Copper (Cu) <0.08% Tensile Variance <0.01% Section Width Tolerance <0.1% Section Height Tolerance <0.1% Section Perpendicular Tolerance <0.1% Ferrite Microstructure % <0.190% Peralite Microstructure % <0.190% Cementite Microstructure % <0.190% Nodule Microstructure adet/mm 100-125 Nodule Maximum size Q/mm 8 Micro Nodularity % 80% + Hardness (HB) 150-250 Tensile Strength N/mm 400 + Elongation 3+ Sand Tempreture on Casting 20°c-45°c Casting Humidity 3.2%-4.0% Wet Compressive Strength 2100-2500gr/cm sq Tensile Strength 20-30gr/cm sq Shatter Index 67-77% Volatile Inclusions <0.001%
All Cast Iron Radiator sections are tested for vertical and horizontal tolerances.
All cast iron radiator sections are tested for vertical and horizontal tolerances. - Specification Table
-
CRANE Historic 3 Column 1050mm Cast Iron Radiators
Radiator Height:
1050mm
(approx. 41 3/8”)
Radiator Depth:
110mm
(approx. 4 3/8”)
Product Sections Radiator Width (L) Heat Output (ΔT=50) Code (No.) mm Inches Watts BTU's C3C-1050-03 3 210mm 8 1/4” 369 Watts 1260 BTU's C3C-1050-04 4 270mm 10 5/8” 492 Watts 1680 BTU's C3C-1050-05 5 330mm 13” 615 Watts 2100 BTU's C3C-1050-06 6 390mm 15 3/8” 738 Watts 2520 BTU's C3C-1050-07 7 450mm 17 3/4” 861 Watts 2940 BTU's C3C-1050-08 8 510mm 20 1/8” 984 Watts 3360 BTU's C3C-1050-09 9 570mm 22 1/2” 1107 Watts 3780 BTU's C3C-1050-10 10 630mm 24 3/4” 1230 Watts 4200 BTU's C3C-1050-11 11 690mm 27 1/8” 1353 Watts 4620 BTU's C3C-1050-12 12 750mm 29 1/2” 1476 Watts 5040 BTU's C3C-1050-13 13 810mm 31 7/8” 1599 Watts 5460 BTU's C3C-1050-14 14 870mm 34 1/4” 1722 Watts 5880 BTU's C3C-1050-15 15 930mm 36 5/8” 1845 Watts 6300 BTU's C3C-1050-16 16 990mm 39” 1968 Watts 6720 BTU's C3C-1050-17 17 1050mm 41 3/8” 2091 Watts 7140 BTU's C3C-1050-18 18 1110mm 43 3/4” 2214 Watts 7560 BTU's C3C-1050-19 19 1170mm 46 1/8” 2337 Watts 7980 BTU's C3C-1050-20 20 1230mm 48 3/8” 2460 Watts 8400 BTU's C3C-1050-21 21 1290mm 50 3/4” 2583 Watts 8820 BTU's C3C-1050-22 22 1350mm 53 1/8” 2706 Watts 9240 BTU's C3C-1050-23 23 1410mm 55 1/2” 2829 Watts 9660 BTU's C3C-1050-24 24 1470mm 57 7/8” 2952 Watts 10080 BTU's C3C-1050-25 25 1530mm 60 1/4” 3075 Watts 10500 BTU's C3C-1050-26 26 1590mm 62 5/8” 3198 Watts 10920 BTU's C3C-1050-27 27 1650mm 65” 3321 Watts 11340 BTU's C3C-1050-28 28 1710mm 67 3/8” 3444 Watts 11760 BTU's C3C-1050-29 29 1770mm 69 5/8” 3567 Watts 12180 BTU's C3C-1050-30 30 1830mm 72” 3690 Watts 12600 BTU's C3C-1050-31 31 1890mm 74 3/8” 3813 Watts 13020 BTU's C3C-1050-32 32 1950mm 76 3/4” 3936 Watts 13440 BTU's C3C-1050-33 33 2010mm 79 1/8” 4059 Watts 13860 BTU's C3C-1050-34 34 2070mm 81 1/2” 4182 Watts 14280 BTU's C3C-1050-35 35 2130mm 83 7/8” 4305 Watts 14700 BTU's C3C-1050-36 36 2190mm 86 1/4” 4428 Watts 15120 BTU's C3C-1050-37 37 2250mm 88 5/8” 4551 Watts 15540 BTU's - Find a Stockist
-
