CRANE® Historic 2 Column Cast Iron Radiators – 750mm
- Description
-
The 750mm CRANE® Historic 2 Column Cast Iron Radiator is a classic choice for bedrooms, hallways and period rooms where you want a little more presence and output, without the depth of a multi-column radiator.
With clean proportions, smooth rounded corners and strong feet, this is a timeless radiator style that sits comfortably in Victorian and Edwardian interiors — and looks equally at home in refined modern schemes.
All CRANE® radiators are assembled and pressure tested in the United Kingdom and supplied with a Lifetime Guarantee.
- Customisation and Finishes
-
CRANE Cast Iron Radiators are cast in Europe and assembled and finished at our UK facility.
CRANE Radiators are available painted in any RAL colour, and we also offer a wide range of specialist finishes including polished options from satin to near mirror.
- Technical Data
-
Section Height 750mm BTU's per section 210 Watts per section 62 Radiator Depth 70mm Section Length 60mm Carbon (C) 3.40%-3.85% Silicon (Si) 1.80%-2.10% Sulfur (S) <0.06% Phosphorus (P) <0.10% Manganese (Mn) 0.40%-0.85% Chromium (Cr) <0.07% Copper (Cu) <0.08% Tensile Variance <0.01% Section Width Tolerance <0.1% Section Height Tolerance <0.1% Section Perpendicular Tolerance <0.1% Ferrite Microstructure % <0.190% Peralite Microstructure % <0.190% Cementite Microstructure % <0.190% Nodule Microstructure adet/mm 100-125 Nodule Maximum size Q/mm 8 Micro Nodularity % 80% + Hardness (HB) 150-250 Tensile Strength N/mm 400 + Elongation 3+ Sand Tempreture on Casting 20°c-45°c Casting Humidity 3.2%-4.0% Wet Compressive Strength 2100-2500gr/cm sq Tensile Strength 20-30gr/cm sq Shatter Index 67-77% Volatile Inclusions <0.001%
All Cast Iron Radiator sections are tested for vertical and horizontal tolerances.
All cast iron radiator sections are tested for vertical and horizontal tolerances. - Sectional Retail Prices
-
Units:Prices:
Product code Section Height Section Width Section Weight Watts Δ50 BTU Δ50 Painted (ex VAT) Precious Metal (ex VAT) HC2-500 500mm 60mm 3kg 47 160 £43 £60 HC3-500 500mm 60mm 4kg 53 180 £46 £65 HC4-500 500mm 60mm 5kg 70 238 £48 £66 HC2-650 650mm 60mm 4kg 53 180 £46 £70 HC3-650 650mm 60mm 5kg 73 250 £53 £78 HC4-650 650mm 60mm 6kg 94 320 £58 £83 HC2-750
750mm 60mm 5kg 61 210 £48 £72 HC3-750 750mm 60mm 6kg 88 300 £62 £87 HC4-750 750mm 60mm 7kg 110 375 £60 £85 HC2-1050 1050mm 60mm 6kg 89 300 £60 £90 HC3-1050 1050mm 60mm 7kg 123 420 £71 £111 HC4-1050 1050mm 60mm 8kg 152 520 £83 £114 The Length of a Radiator is the number of sections multiplied by the Section Width, plus 30mm (15mm for each end cap).
- Specification Table
-
CRANE Historic 2 Column 750mm Cast Iron Radiators
Radiator Height:
750mm
(approx. 29 1/2”)
Radiator Depth:
70mm
(2 ¾”)
Product Sections Radiator Width (L) Heat Output (ΔT=50) Code (No.) mm Inches Watts BTU's C2C-750-03 3 210mm 8 1/4” 186 Watts 630 BTU's C2C-750-04 4 270mm 10 5/8” 248 Watts 840 BTU's C2C-750-05 5 330mm 13” 310 Watts 1050 BTU's C2C-750-06 6 390mm 15 3/8” 372 Watts 1260 BTU's C2C-750-07 7 450mm 17 3/4” 434 Watts 1470 BTU's C2C-750-08 8 510mm 20 1/8” 496 Watts 1680 BTU's C2C-750-09 9 570mm 22 1/2” 558 Watts 1890 BTU's C2C-750-10 10 630mm 24 3/4” 620 Watts 2100 BTU's C2C-750-11 11 690mm 27 1/8” 682 Watts 2310 BTU's C2C-750-12 12 750mm 29 1/2” 744 Watts 2520 BTU's C2C-750-13 13 810mm 31 7/8” 806 Watts 2730 BTU's C2C-750-14 14 870mm 34 1/4” 868 Watts 2940 BTU's C2C-750-15 15 930mm 36 5/8” 930 Watts 3150 BTU's C2C-750-16 16 990mm 39” 992 Watts 3360 BTU's C2C-750-17 17 1050mm 41 3/8” 1054 Watts 3570 BTU's C2C-750-18 18 1110mm 43 3/4” 1116 Watts 3780 BTU's C2C-750-19 19 1170mm 46 1/8” 1178 Watts 3990 BTU's C2C-750-20 20 1230mm 48 3/8” 1240 Watts 4200 BTU's C2C-750-21 21 1290mm 50 3/4” 1302 Watts 4410 BTU's C2C-750-22 22 1350mm 53 1/8” 1364 Watts 4620 BTU's C2C-750-23 23 1410mm 55 1/2” 1426 Watts 4830 BTU's C2C-750-24 24 1470mm 57 7/8” 1488 Watts 5040 BTU's C2C-750-25 25 1530mm 60 1/4” 1550 Watts 5250 BTU's C2C-750-26 26 1590mm 62 5/8” 1612 Watts 5460 BTU's C2C-750-27 27 1650mm 65” 1674 Watts 5670 BTU's C2C-750-28 28 1710mm 67 3/8” 1736 Watts 5880 BTU's C2C-750-29 29 1770mm 69 5/8” 1798 Watts 6090 BTU's C2C-750-30 30 1830mm 72” 1860 Watts 6300 BTU's C2C-750-31 31 1890mm 74 3/8” 1922 Watts 6510 BTU's C2C-750-32 32 1950mm 76 3/4” 1984 Watts 6720 BTU's C2C-750-33 33 2010mm 79 1/8” 2046 Watts 6930 BTU's C2C-750-34 34 2070mm 81 1/2” 2108 Watts 7140 BTU's C2C-750-35 35 2130mm 83 7/8” 2170 Watts 7350 BTU's C2C-750-36 36 2190mm 86 1/4” 2232 Watts 7560 BTU's C2C-750-37 37 2250mm 88 5/8” 2294 Watts 7770 BTU's - Find a Stockist
-
