CRANE® Historic 2 Column Cast Iron Radiators – 1050mm
- Description
-
The 1050mm CRANE® Historic 2 Column Cast Iron Radiator is a tall, elegant choice for period properties — delivering strong heat output with a slim front-to-back profile.
With clean proportions, smooth rounded corners and confident feet, it suits Victorian and Edwardian interiors beautifully, while also adding character to modern schemes that need a touch of heritage.
All CRANE® radiators are assembled and pressure tested in the United Kingdom and supplied with a Lifetime Guarantee.
- Customisation and Finishes
-
CRANE Cast Iron Radiators are cast in Europe and assembled and finished at our UK facility.
CRANE Radiators are available painted in any RAL colour, and we also offer a wide range of specialist finishes including polished options from satin to near mirror.
- Technical Data
-
Section Height 1050mm BTU's per section 300 Watts per section 89 Radiator Depth 70mm Section Length 60mm Carbon (C) 3.40%-3.85% Silicon (Si) 1.80%-2.10% Sulfur (S) <0.06% Phosphorus (P) <0.10% Manganese (Mn) 0.40%-0.85% Chromium (Cr) <0.07% Copper (Cu) <0.08% Tensile Variance <0.01% Section Width Tolerance <0.1% Section Height Tolerance <0.1% Section Perpendicular Tolerance <0.1% Ferrite Microstructure % <0.190% Peralite Microstructure % <0.190% Cementite Microstructure % <0.190% Nodule Microstructure adet/mm 100-125 Nodule Maximum size Q/mm 8 Micro Nodularity % 80% + Hardness (HB) 150-250 Tensile Strength N/mm 400 + Elongation 3+ Sand Tempreture on Casting 20°c-45°c Casting Humidity 3.2%-4.0% Wet Compressive Strength 2100-2500gr/cm sq Tensile Strength 20-30gr/cm sq Shatter Index 67-77% Volatile Inclusions <0.001%
All Cast Iron Radiator sections are tested for vertical and horizontal tolerances.
All cast iron radiator sections are tested for vertical and horizontal tolerances. - Sectional Retail Prices
-
Units:Prices:
Product code Section Height Section Width Section Weight Watts Δ50 BTU Δ50 Painted (ex VAT) Precious Metal (ex VAT) HC2-500 500mm 60mm 3kg 47 160 £43 £60 HC3-500 500mm 60mm 4kg 53 180 £46 £65 HC4-500 500mm 60mm 5kg 70 238 £48 £66 HC2-650 650mm 60mm 4kg 53 180 £46 £70 HC3-650 650mm 60mm 5kg 73 250 £53 £78 HC4-650 650mm 60mm 6kg 94 320 £58 £83 HC2-750 750mm 60mm 5kg 61 210 £48 £72 HC3-750 750mm 60mm 6kg 88 300 £62 £87 HC4-750 750mm 60mm 7kg 110 375 £60 £85 HC2-1050
1050mm 60mm 6kg 89 300 £60 £90 HC3-1050 1050mm 60mm 7kg 123 420 £71 £111 HC4-1050 1050mm 60mm 8kg 152 520 £83 £114 The Length of a Radiator is the number of sections multiplied by the Section Width, plus 30mm (15mm for each end cap).
- Specification Table
-
CRANE Historic 2 Column 1050mm Cast Iron Radiators
Radiator Height:
1050mm
(approx. 41 3/8”)
Radiator Depth:
70mm
(2 ¾”)
Product Sections Radiator Width (L) Heat Output (ΔT=50) Code (No.) mm Inches Watts BTU's C2C-1050-03 3 210mm 8 1/4” 267 Watts 900 BTU's C2C-1050-04 4 270mm 10 5/8” 356 Watts 1200 BTU's C2C-1050-05 5 330mm 13” 445 Watts 1500 BTU's C2C-1050-06 6 390mm 15 3/8” 534 Watts 1800 BTU's C2C-1050-07 7 450mm 17 3/4” 623 Watts 2100 BTU's C2C-1050-08 8 510mm 20 1/8” 712 Watts 2400 BTU's C2C-1050-09 9 570mm 22 1/2” 801 Watts 2700 BTU's C2C-1050-10 10 630mm 24 3/4” 890 Watts 3000 BTU's C2C-1050-11 11 690mm 27 1/8” 979 Watts 3300 BTU's C2C-1050-12 12 750mm 29 1/2” 1068 Watts 3600 BTU's C2C-1050-13 13 810mm 31 7/8” 1157 Watts 3900 BTU's C2C-1050-14 14 870mm 34 1/4” 1246 Watts 4200 BTU's C2C-1050-15 15 930mm 36 5/8” 1335 Watts 4500 BTU's C2C-1050-16 16 990mm 39” 1424 Watts 4800 BTU's C2C-1050-17 17 1050mm 41 3/8” 1513 Watts 5100 BTU's C2C-1050-18 18 1110mm 43 3/4” 1602 Watts 5400 BTU's C2C-1050-19 19 1170mm 46 1/8” 1691 Watts 5700 BTU's C2C-1050-20 20 1230mm 48 3/8” 1780 Watts 6000 BTU's C2C-1050-21 21 1290mm 50 3/4” 1869 Watts 6300 BTU's C2C-1050-22 22 1350mm 53 1/8” 1958 Watts 6600 BTU's C2C-1050-23 23 1410mm 55 1/2” 2047 Watts 6900 BTU's C2C-1050-24 24 1470mm 57 7/8” 2136 Watts 7200 BTU's C2C-1050-25 25 1530mm 60 1/4” 2225 Watts 7500 BTU's C2C-1050-26 26 1590mm 62 5/8” 2314 Watts 7800 BTU's C2C-1050-27 27 1650mm 65” 2403 Watts 8100 BTU's C2C-1050-28 28 1710mm 67 3/8” 2492 Watts 8400 BTU's C2C-1050-29 29 1770mm 69 5/8” 2581 Watts 8700 BTU's C2C-1050-30 30 1830mm 72” 2670 Watts 9000 BTU's C2C-1050-31 31 1890mm 74 3/8” 2759 Watts 9300 BTU's C2C-1050-32 32 1950mm 76 3/4” 2848 Watts 9600 BTU's C2C-1050-33 33 2010mm 79 1/8” 2937 Watts 9900 BTU's C2C-1050-34 34 2070mm 81 1/2” 3026 Watts 10200 BTU's C2C-1050-35 35 2130mm 83 7/8” 3115 Watts 10500 BTU's C2C-1050-36 36 2190mm 86 1/4” 3204 Watts 10800 BTU's C2C-1050-37 37 2250mm 88 5/8” 3293 Watts 11100 BTU's - Find a Stockist
-
